Known for crisp module definition, stylish and sustainable design, our Multi-Box Ceilings offer solutions made with up to 92% recycled aluminum. This adaptable metal ceiling works well in interior and exterior applications.

MAXIMIZE OPTIONS IN DESIGN.

The key feature of this system is the unlimited combination of panel depths and widths using Box and Deep Box ceilings. The benefit is maximum versatility in design.

PRODUCT DETAILS

Panel sizes:

  • Panel module widths: 2″, 4″, 6″ and 8″
  • Panel lengths: 3′ to 16′
  • Panel depths (nominal):
  • 5/8″ (Box 2, 4, 6 & 8)
  • 1-1/2″ (Deep Box 2)
  • 1″ (Deep Box 4, 6 & 8)

Key Features

  • Square-edge design
  • Curved carrier application available
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Easy plenum access
  • Interior and exterior applications
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
  • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Film on metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Wood veneer on metal: Flame spread: ≤ 25, Smoke ≤ 55 (for interior applications)
  • Weight: Varies 0.5 – 1.0 lbs/sq. ft.
  • Wind load: Per code (for exterior applications)
  • Recycled content: Up to 92%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
  • Cotton White: LR = 0.81

Colors & Finishes

Finish Options
