CLASSIC DESIGN. INFINITE POSSIBILITIES.

The key feature of this system is the ease of installation. The benefit is no tools or fasteners required and easy access to plenum space.

PRODUCT DETAILS

Two panel size sets:

• 6″, 12″, 18″, 20″, 24″ widths up to 96″ long
• 30″ width up to 60″ long

Key Features

• Edge options: square, flush, reveal
• Curved Lay-in available
• Waste reduction with factory fabricated dimensional material
• Downweight: reduce dead load with lightweight aluminum
• Easy installation – no fasteners/tools required
• Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
• High recycled aluminum content
• No VOCs: No added urea-formaldehyde
• GREENGUARD Gold Certified

Physical Data

• Substrate: Aluminum
• Warranty: 1 year
• Seismic rating: Zones A, B, C, D, E, F
• Fire rating: Class A Fire Rated per ASTM E84
• Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
• Weight: Varies 0.75 – 1.0 lbs/sq. ft.
• Wind load: N/A
• Recycled content: Up to 85%
• Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
• Cotton White: LR = 0.81
