CREATE A FOCAL POINT.

Metal wall ceilings provide seamless integration with ceiling systems.

PRODUCT DETAILS

Available panel sizes include:
Pedestrian Level:

• Preferred for panels within reach (e.g. up to 8′ height)
• 6″ x 12″ up to 48″ x 120″

Acoustical Level:

• Preferred for panels out of reach (e.g. above 8′ height)
• 6″ x 12″ up to 30″ x 120″

Key Features

• Aluminum or stainless steel substrate
• Square-edge design with flush or reveal joints
• Waste reduction with factory fabricated dimensional material
• Downweight: reduces dead load with lightweight aluminum
• GREENGUARD Gold Certified

Physical Data

• Substrate: Non-woven PES fibers (felt)
• Warranty: 1 year
• Seismic rating: Zones A, B, C, D, E, F
• Fire rating: Class A Fire Rated per ASTM E84
• Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
• Film on metal: Flame spread: ≤ 25, Smoke ≤ 50
• Wood veneer on metal: Flame spread: ≤ 25, Smoke ≤ 55 (for interior applications)
• Weight: Varies
• Wind load: N/A
• Recycled content: Up to 85%
• Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
• Cotton White: LR = 0.81
