BREAK THE CEILING PLANE.

HeartFelt Levels adds dimensionality to your space, with varied depths and reveals, allowing you to create customizable and aesthetically stunning ceiling spaces.

PRODUCT DETAILS

Panel sizes:

• Panel dimensions: 1 9/16″ x 2 3/16″ (40 mm x 55 mm)
• Panel length: 8′
• Full system depth: 3-9/16″ to 4-9/16″ with up to 1″ reveal

Key Features

• Modular ceiling system with felt panels
• Square-edge design
• Carrier modules available for step, scatter, wave, and choppy visuals
• Custom carrier modules available upon request
• Easy plenum access
• Interior applications
• Compatible with industry standard lighting, HVAC, speaker, fire safety, and security services
• GREENGUARD Gold Certified
• Cradle to Cradle Certified™ Bronze

Physical Data

• Substrate: Non-woven PES fibers (felt)
• Warranty: 1 year
• Seismic rating: Zones A, B, C, D, E, F
• Fire rating: US – Class A Fire Rated per ASTM E84
• Flame spread: ≤ 25, Smoke ≤ 300
• Fire rating: Canada – per CAN/ULC S102.2-10
• Flame spread: = 5, Smoke = 90
• Weight: Varies
• Wind load: N/A
• Made of virgin PET; 100% recyclable
• Light reflectance: Varies with color selected
