PRECISION IN DESIGN AND ACOUSTICAL PERFORMANCE.

The key feature of this system is the precise directional control. The benefit is the system supports virtually any design configuration.

PRODUCT DETAILS

Panel sizes:

• Panel module width: 4″
• Panel lengths: 3′ to 16′
• Panel depth: 5/8″

Key Features

• Round-edge design
• Curved carrier application available
• Waste reduction with factory fabricated dimensional material
• Downweight: reduce dead load with lightweight aluminum
• Easy plenum access
• Interior applications only
• Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
• High recycled aluminum content
• GREENGUARD Gold Certified

Physical Data

• Substrate: Aluminum
• Warranty: 1 year
• Seismic rating: Zones A, B, C, D, E, F
• Fire rating: Class A Fire Rated per ASTM E84
• Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
• Film on metal: Flame spread: ≤ 25, Smoke ≤ 50
• Weight: Varies 0.5 – 0.75 lbs/sq. ft.
• Wind load: N/A
• Recycled content: Up to 92%
• Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
• Cotton White: LR = 0.81
