Panel Sizes

• 8’ planks available in closed (tongue & groove) or open reveal format
• ¾” thickness

Key Features
Veneered Planks:

• 14 standard veneers available
• Open reveal options available in two linear patterns
• Achieve up to NRC 0.80 with channeled options or 0.40 with Theatre® Black f 1″ acoustic panel infill

Solid Wood Planks:

• Six simulated solid wood finishes available
• Available in two plank widths with ¾” felt reveal (3-¾” or 5-¼”)

Physical Data

• Material: Fire-retardant particle board, fire-retardant MDF, or solid basswood; plywood backer
• Surface finish: Clear or tinted topcoat with 20% sheen and acoustical felt
• Warranty: 1-year limited warranty

• Solid Basswood Planks
• Fire rating: Class C per ASTM E84
• Flame spread: 200 or less
• Smoke developed: 450 or less

• Particle Board Linear Planks
• Fire rating: Class A per ASTM E84
• Flame spread: 25 or less
• Smoke developed: 50 or less
• Weight: 1.4 – 3 lbs./sq. ft
