PRODUCT DETAILS

Panel Sizes & Edges

• Available in 1’ x 8’ modules
• Available configurations: Backer (B1), Dowel (D1), Backer & Dowel (BD), Flexible Backer (B2)
• Number of blades, blade width, and blade height vary by configuration – refer to the data sheet for specific combinations

Key Features

• Available in a variety of blade depths, widths, and number of blades to enable design flexibility and unique installations
• Ability to create a curved installation with the flexible backer configuration
• Six standard simulated finishes available on basswood
• NRC up to 0.90 when installed with Theatre® Black f 1″ acoustic panel infill
• Additional special order finishes, sizes, and configurations available; contact your local sales representative for more information

Physical Data

• Material: Solid Basswood blades; plywood backers; poplar dowels
• Surface finish: Clear or tinted topcoat with 20% sheen
• Warranty: 1-year limited warranty
• Fire rating: Class C per ASTM E84/ULC S102
• Flame spread: 200 or less
• Smoke developed: 450 or less
• Weight: 0.9-3.3 lbs./sq. ft.
