UNPARALLELED DURABILITY WITHOUT SACRIFICING STYLE.

With a Miami-Dade rating the 150F Exterior ceiling system is designed to withstand exterior environments and wind loading.

PRODUCT DETAILS

Panel sizes:

• Panel width: 6″ nom. [150 mm]
• Panel lengths: 3′ to 20′
• Panel depth: 11/16″

Key Features

• Bevel-edge design
• Waste reduction with factory fabricated dimensional material
• Downweight: reduce dead load with lightweight aluminum
• Interior and exterior applications
• Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
• Luxacote® high-performance finish resists exterior environmental conditions including UV
• Perforated panels are available only for exterior ventilation and may not exceed 10% of total ceiling area
• Factory assembled access doors available
• Miami-Dade NOA 19-0214.01 (expires May 5, 2021)
• High recycled aluminum content
• No VOCs: No added urea-formaldehyde
• GREENGUARD Gold Certified

Physical Data

• Substrate: Aluminum
• Warranty: 1 year
• Seismic rating: Zones A, B, C, D, E, F
• Fire rating: Class A Fire Rated per ASTM E84
• Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
• Weight: 0.75 lbs/sq. ft.
• Wind load: Per code
• Designed and tested in accordance with the requirements of the Florida Building Code 5th edition (2014), including the High Velocity Hurricane Zone (HVHZ) provisions and Miami-Dade requirements.
• Miami-Dade NOA 19-0214.01 (expires May 5, 2021)
• Recycled content: Up to 92%
• Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
• Cotton White: LR = 0.81
